SILVER DECO FRAME
PSP9 to PSP2020

This tutorial was written by Jemima ~JANUARY 2020
Copyright © 2020 ~ Jemima ~ All rights reserved

This was created using PSP9 but can be adapted for other versions of PSP.

********************************
The fair use of a copyrighted work for nonprofit educational for purposes such as teaching is not an infringement of copyright.
No artists or copyright infringement is intended on any of the tubes used in this tutorial.
The tubes were acquired in good faith as to their legality.
If there is a problem, please contact the author and the image/s will be removed.

You will need the following to complete this tutorial

Materials

Save to a folder on your computer

********************************

Plugins
SIMPLE
** PLUGINS_LINKS **
HERE

********************************

You can drag this hand down the page with you to keep your place in the tut.

STEP 1 Open up the Wallpaper_ea3c image in your PSP workspace PSP9: IMAGE >>> ROTATE >>> FREE ROTATE = RIGHT 90 Ensure "All layers" is UNCHECKED PSPX - PSP2020: IMAGE >>> FREE ROTATE = RIGHT 90 Ensure "All layers" is UNCHECKED Right click on the Title Bar and select COPY from the options . .
STEP 2 Open a new image 800 x 600 Transparent background PSP9: Colour Depth = 16 Million Colors (24bit) PSPX - PSP2020: Colour Depth RGB = 8bits/channel Choose your SELECTION TOOL then click on the CUSTOM SELECTION symbol and enter these coordinates.
STEP 3 Right click on the Title Bar of your frame image and select PASTE INTO SELECTION from the options. DESELECT LAYERS >>> DUPLICATE PSP9 - PSPX3: IMAGE >>> FLIP PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) LAYERS >>> MERGE >>> MERGE DOWN PSP9 - PSPX3: IMAGE >>> MIRROR PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) SAVE YOUR WORK ,
STEP 4 EFFECTS >>> PLUGINS >>> SIMPLE >>> TOP LEFT MIRROR EFFECTS >>> DISTORTION EFFECTS >>> POLAR COORDINATES Polar to Rectangular PSP9 - PSPX3: IMAGE >>> FLIP PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) EFFECTS >>> PLUGINS >>> SIMPLE >>> TOP LEFT MIRROR SAVE YOUR WORK
STEP 5 LAYERS >>> DUPLICATE PSP9: IMAGE >>> ROTATE >>> FREE ROTATE = RIGHT 90 Ensure "All layers" is UNCHECKED PSPX - PSP2020: IMAGE >>> FREE ROTATE = RIGHT 90 Ensure "All layers" is UNCHECKED IMAGE >>> RESIZE = 71% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN
STEP 6 ACTIVATE Raster 1 IMAGE >>> RESIZE = 95% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN ,
STEP 7 CLOSE Raster 1 ACTIVATE Copy of Raster 1 With your MAGIC WAND Mode = Replace Match Mode = RGB Value Tolerance = 0 Feather = 0 Antialias = Checked Sample Merged = UNCHECKED PSP9 - PSP2019: Check CONTIGUOUS PSPX - PSP2019: There is no " Sample Merged" PSP9 - PSP2019: Use all layers = UNChecked PSP9 - PSP2019: ANTIALIAS = Outside Select the OUTER transparent area SELECTIONS >>> INVERT
STEP 8 SELECTIONS >>> MODIFY >>> CONTRACT = 10 EDIT >>> CLEAR OPEN & ACTIVATE Raster 1 SELECTIONS >>> MODIFY >>> EXPAND = 10 EDIT >>> CLEAR DESELECT SAVE YOUR WORK ,
STEP 9 ACTIVATE Copy of Raster 1 LAYERS >>> DUPLICATE IMAGE >>> RESIZE = 90% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN LAYERS >>> MERGE >>> MERGE DOWN
STEP 10 EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 2 Colour = Black Opacity = 80 Blur = 0.00 ACTIVATE Raster 1 EDIT >>> Repeat Drop Shadow Repeat Drop Shadow effect changing Vertical & Horizontal Offsets to - ( minus ) 2 ACTIVATE Copy of Raster 1 EDIT >>> Repeat Drop Shadow ,
STEP 11 In your MATERIALS PALETTE Load LIGHT GREY " #dddddd " in your foreground Load DARK GREY " #676869 " in your background Then click on the GRADIENT option in your foreground palette Select the Foreground-background option. STYLE = Linear Use these settings ,
STEP 12 With your MAGIC WAND ... Same settings Select the area indicated ,
STEP 13 Flood fill with the GRADIENT EFFECTS >>> 3D EFFECTS >>> INNER BEVEL COLOR = #eeecec DESELECT SAVE YOUR WORK
STEP 14 ACTIVATE Raster 1 With your MAGIC WAND ... Same settings Select the OUTER transparent area Flood fill with the GRADIENT EFFECTS >>> 3D EFFECTS >>> INNER BEVEL Same settings DESELECT
STEP 15 ACTIVATE Copy of Raster 1 EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 5 Colour = Black Opacity = 80 Blur = 12.00 Repeat Drop Shadow effect changing Vertical & Horizontal Offsets to - ( minus ) 5 LAYERS >>> MERGE >>> MERGE VISIBLE SAVE YOUR WORK ,
STEP 16 Open up the flora10 image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. PSP9 - PSPX3: IMAGE >>> FLIP PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) IMAGE >>> RESIZE = 70% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN EFFECTS >>> IMAGE EFFECTS >>> OFFSET Horizontal Offset = - ( minus ) 289 Vertical Offset = 195 Edge Mode = Transparent
STEP 17 EFFECTS >>> PLUGINS >>> SIMPLE >>> TOP LEFT MIRROR EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 5 Colour = Black Opacity = 80 Blur = 12.00 LAYERS >>> MERGE >>> MERGE VISIBLE SAVE YOUR WORK , ,
STEP 18 LAYERS >>> NEW RASTER LAYER SELECTIONS >>> SELECT ALL Flood fill with BLACK SELECTIONS >>> MODIFY >>> CONTRACT = 2 EDIT >>> CLEAR DESELECT LAYERS >>> MERGE >>> MERGE VISIBLE Save as .pspimage image
STEP 19 Open up the Background852 image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 75% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN ADJUST >>> HUE & SATURATION >>> COLORIZE Hue = 0 Saturation = 0 LAYERS >>> ARRANGE >>> MOVE DOWN ,
STEP 20 Open up the COUPLE_093 image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 75% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN EFFECTS >>> IMAGE EFFECTS >>> OFFSET Horizontal Offset = 0 Vertical Offset = - ( minus ) 55 Edge Mode = Transparent LAYERS >>> MERGE >>> MERGE VISIBLE,
STEP 21 LAYERS >>> NEW RASTER LAYER Select your TEXT tool and with a font of your choice add your name,
STEP 22 LAYERS >>> MERGE >>> MERGE ALL (Flatten) Save as .jpg image ,
