PURPLE POWER FRAME
PSP9 to PSP2020

This tutorial was written by Jemima ~JANUARY 2020
Copyright © 2020 ~ Jemima ~ All rights reserved

This was created using PSP9 but can be adapted for other versions of PSP.

********************************
The fair use of a copyrighted work for nonprofit educational for purposes such as teaching is not an infringement of copyright.
No artists or copyright infringement is intended on any of the tubes used in this tutorial.
The tubes were acquired in good faith as to their legality.
If there is a problem, please contact the author and the image/s will be removed.

You will need the following to complete this tutorial

Materials

antique vector.png
decos-71.pspimage
Save to a folder on your computer

********************************

Plugins
SIMPLE
** PLUGINS_LINKS **
HERE

********************************

You can drag this hand down the page with you to keep your place in the tut.

STEP 1 Open a new image 800 x 600 Transparent background PSP9: Colour Depth = 16 Million Colors (24bit) PSPX - PSP2020: Colour Depth RGB = 8bits/channel SELECTIONS >>> SELECT ALL Open up the wallpaperb92c image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE INTO SELECTION from the options. DESELECT PSP9 - PSPX3: IMAGE >>> FLIP PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) EFFECTS >>> PLUGINS >>> SIMPLE >>> TOP LEFT MIRROR
STEP 2 IMAGE >>> RESIZE = 85% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN Open up the element-ppf image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options.
STEP 3 With your MAGIC WAND Mode = Replace Match Mode = RGB Value Tolerance = 0 Feather = 2 Antialias = Checked Sample Merged = UNCHECKED PSP9 - PSP2019: Check CONTIGUOUS PSPX - PSP2019: There is no " Sample Merged" PSP9 - PSP2019: Use all layers = UNChecked PSP9 - PSP2019: ANTIALIAS = Outside , Select the red element ACTIVATE Raster 1 EDIT >>> CLEAR DESELECT DELETE Raster 2 SAVE YOUR WORK
STEP 4 EFFECTS >>> DISTORTION EFFECTS >>> PUNCH Strength = 100% IMAGE >>> RESIZE = 95% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN ADJUST >>> HUE & SATURATION >>> COLORIZE Hue = 180 Saturation = 80
STEP 5 In your MATERIALS PALETTE Load LILAC " #c0b9da " in your foreground Load PURPLE " #413668 " in your background Then click on the GRADIENT option in your foreground palette Select the Foreground-background option. STYLE = Linear
STEP 6 LAYERS >>> NEW RASTER LAYER Flood fill with the GRADIENT LAYERS >>> ARRANGE >>> MOVE DOWN LAYERS >>> DUPLICATE PSP9 - PSPX3: IMAGE >>> MIRROR PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) SELECTIONS >>> SELECT ALL SELECTIONS >>> MODIFY >>> CONTRACT = 20 SELECTIONS >>> INVERT EDIT >>> CLEAR SELECTIONS >>> INVERT
STEP 7 In your MATERIALS PALETTE change the Gradient "Repeats" to = 20 LAYERS >>> NEW RASTER LAYER Flood fill with the GRADIENT SELECTIONS >>> MODIFY >>> CONTRACT = 6 EDIT >>> CLEAR DESELECT EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 1 Colour = Black Opacity = 70 Blur = 0.00 Repeat Drop Shadow effect changing Vertical & Horizontal Offsets to - ( minus ) 1 ,SAVE YOUR WORK
STEP 8 ACTIVATE Raster 1 Choose your SELECTION TOOL On the top menu select 'Create selection from: LAYERS >>> NEW RASTER LAYER Flood fill with the GRADIENT SELECTIONS >>> MODIFY >>> CONTRACT = 5 EDIT >>> CLEAR DESELECT Repeat BOTH Drop Shadows
STEP 9 ACTIVATE Raster 1 With your MAGIC WAND ....Same settings Select the CENTRE of your image SELECTIONS >>> MODIFY >>> EXPAND = 7 ACTIVATE Copy of Raster 2 EDIT >>> CLEAR ACTIVATE Raster 2 EDIT >>> CLEAR DESELECT SAVE YOUR WORK
STEP 10 ACTIVATE Raster 1 Open up the decos-71 image in your PSP workspace Activate Raster 1 Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 50% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN EFFECTS >>> IMAGE EFFECTS >>> OFFSET Horizontal Offset = - ( minus ) 305 Vertical Offset = 145 Edge Mode = Transparent
STEP 11 EFFECTS >>> PLUGINS >>> SIMPLE >>> TOP LEFT MIRROR SAVE YOUR WORK
STEP 12 Open up the antique vector image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 75% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN EFFECTS >>> IMAGE EFFECTS >>> OFFSET Horizontal Offset = 0 Vertical Offset = 230 Edge Mode = Transparent,
STEP 13 LAYERS >>> DUPLICATE PSP9 - PSPX3: IMAGE >>> FLIP PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) PSP9 - PSPX3: IMAGE >>> MIRROR PSPX4 - PSPX8: Use script available for download at top of page. (Higher versions follow your version's method) LAYERS >>> MERGE >>> MERGE DOWN ,
STEP 14 ACTIVATE Raster 4 EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 2 Colour = Black Opacity = 70 Blur = 5.00 ACTIVATE Raster 3 EDIT >>> Repeat Drop Shadow Repeat Drop Shadow effect changing Vertical & Horizontal Offsets to - ( minus ) 2 ACTIVATE Raster 4 EDIT >>> Repeat Drop Shadow
STEP 15 LAYERS >>> MERGE >>> MERGE VISIBLE ADJUST >>> SHARPNESS >>> SHARPEN
STEP 16 LAYERS >>> NEW RASTER LAYER Flood fill with PURPLE SELECTIONS >>> SELECT ALL SELECTIONS >>> MODIFY >>> CONTRACT = 5 EDIT >>> CLEAR DESELECT Repeat BOTH Drop Shadows ADJUST >>> SHARPNESS >>> SHARPEN MORE EDIT >>> Repeat Sharpen More LAYERS >>> MERGE >>> MERGE VISIBLE Save as .pspimage image
STEP 17 Open up the balcony image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 85% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN LAYERS >>> ARRANGE >>> MOVE DOWN
STEP 18 Open up the backview image in your PSP workspace Right click on the Title Bar and select COPY from the options Right click on the Title Bar of your frame image and select PASTE AS NEW LAYER from the options. IMAGE >>> RESIZE = 70% Check "Lock aspect ratio." Ensure "Resize all layers" is UNCHECKED Resample using WEIGHTED AVERAGE ADJUST >>> SHARPNESS >>> SHARPEN Reposition down with your MOVER tool
STEP 19 ACTIVATE the Merged Layer EFFECTS >>> 3D EFFECTS >>> DROP SHADOW Vertical & Horizontal offsets = 5 Colour = Black Opacity = 70 Blur = 12.00 Repeat Drop Shadow effect changing Vertical & Horizontal Offsets to - ( minus ) 5
STEP 20 LAYERS >>> MERGE >>> MERGE VISIBLE LAYERS >>> NEW RASTER LAYER Select your TEXT tool and with a font of your choice add your name,
STEP 21 LAYERS >>> MERGE >>> MERGE ALL (Flatten) Save as .jpg image ,
